Rigid Transparent UV Co Extruded PET Sheet Extrusion Machine

Basic Information
Place of Origin: Qingdao, China
Brand Name: Leader
Certification: CE ISO SGS GOST
Model Number: SJ-120/35
Minimum Order Quantity: 1 set
Price: US $150,000-220,000/SET
Packaging Details: plywood pallet
Delivery Time: 90 workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 22 Sets / Year
Name: Rigid Transparent UV Co-extruded PET Sheet Extrusion Machine Material: PET
Extruder Type: Single Screw Extruder SJ120/35 SJ150/35 Thickness: 0.15-1.5mm 0.25-1.5mm
Width: 600mm 800mm 1000mm 1200mm Or Customised Max Capacity: 500kg/h
High Light:

Co Extruded PET Sheet Extrusion Machine


600mm PET Sheet Extrusion Machine

Rigid Transparent UV Co-Extruded PET Sheet Extrusion Machine

Rigid Transparent UV Co-extruded PET Sheet Extrusion Machine​

Rigid Transparent UV Co-extruded PET Sheet Extrusion Machine


Introduction :

This plastic PET sheet extruder extrusion line machine is specially designed for PET mono/multi layer sheet for packing industry . The technology of "single screw extruding with low dew-point dehumidifying system " for high quality products in ihgh transparency without bubble , which will be very important for thermoforming .
Use parallel twin screw extrusion line for PET sheet . Equipped with degassing system, so no need drying or crystalizing unit . Multi components dosing feeder can control the percentage of virgin material, recycling material and master bacth precisely.​ This sheet is widely used for thermoforming packing industry.

Raw material for PET sheet making machine :

Can be virgin plastic PET material
​can be recyclable material , like PET bottle flakes .

Sheet Specification :

Usual sheet width : 300-1500mm or customised
Usual sheet thickness : 0.2-2mm

Consist of PET Sheet Making Machine:

1 1 set of vacuum feeding machine and dryer-cooper
2 single screw extruder for virgin material/ twin screw extruder for recycled mateiral
3 1 set of hydraulic filter exchanging unit
4 1 set of melt pump for PET
5 1 set of T-die head
6 1 set of 3-roller calendar 45 degree with temperature controller for rollers
7 1 set of cooling frame, edge cutting unit and hauling off machine
8 1 set of Double position winding machine


Model Multi Layer Single Layer High-efficient
Extruder Specification sj75&36/40-1000 SJ75/40-1000 SJ95&52/44-1500
Product Thickness 0.15-1.5mm 0.15-1.5mm 0.15-1.5mm
Main Motor Power 110kw/45kw 110kw 250kw/55kw
Max Extrusion Capacity 500kg/h 450kg/h 800-1000kg/h


Rigid Transparent UV Co Extruded PET Sheet Extrusion Machine 0
