| Place of Origin: | ZheJiang, China |
|---|---|
| Brand Name: | MINGDI EXTRUSION |
| Certification: | CE,ISO |
| Model Number: | 75/85 |
| Minimum Order Quantity: | one set |
| Price: | 20000-200000$ |
| Packaging Details: | PE film & wooden pallet packaging |
| Delivery Time: | 90days |
| Payment Terms: | T/T |
| Supply Ability: | 225 sets one year |
| Width: | 1200/1400mm | Thickness: | 0.15-1.2mm |
|---|---|---|---|
| Capacity: | 600/800kg/h | Material: | PP/PS/EVA |
| Application: | Furniture Veneer, Food Packaging, Fruit And Vegtable Packaging,electronic Product Packaging,hot And Cold Drink Cup Lids | Core Component: | Extrusion Machine, Screen Changer, Pressure Sensor, Metering Pump, Extrusion Die, Three-roll Calender, Drawing Machine, Automatic Cutting System, Electrical Control System |
| Warranty Period: | One Year | Core Component Shelf Life: | One Year |
| Suitable Industry: | Food Packaging Industry, Toy Industry, Building Materials Industry, Advertising Industry, Etc | Core Selling Point: | Twin Screw, High Production Capacity And Low Energy Consumption |
| Linear Velocity: | 60m/h | ||
| Highlight: | veneer production line 1200mm,pp veneer production line,pp plastic sheet production line |
||
| Attribute | Value |
|---|---|
| Width | 1200/1400mm |
| Thickness | 0.15-1.2mm |
| Capacity | 600/800kg/h |
| Material | PP/PS/EVA |
| Linear Velocity | 60m/h |
| Warranty Period | One year |
| Feeding Form | Screw-type |
| Feeding Capacity | 1000kg/h |
| Control Mode | Variable frequency motor speed control |
| Converter | SIEMENS 3KW with Ethernet control technology |
| Feed Rate | 1-30kg/h |
| Material Conveying Method | Screw type |
| Drive Motor | 0.4KW Siemens servo motor |
| Control Method | Siemens servo speed control |
| Brand | Touya |
| Structure Form | 175mm Full-network double-column screen changer with hydraulic station |
| Heating Zones | Two zones |
| Heating Power | Approx. 10kw |
| Brand | JingCheng |
| Structure Form | Hanger runner |
| Width of Final Product | 860mm |
| Thickness Range | 0.2-1.0mm |
| Heating Zones | 8 zones |
| Heating Power | 30KW |
| Control System | PLC |
| CPU | SIEMENS S7-1500 |
| HMI | SIEMENS 12 inches |
| Inverters | SIEMENS |
| Circuit Breakers | SIEMENS |
