Polycarbonate Hollow Profile Sheet Extrusion Line UV Protection PLC Control

Basic Information
Place of Origin: Qingdao, China
Brand Name: Leader
Certification: CE ISO SGS GOST
Model Number: SJ120/35 Single Screw Extruder
Minimum Order Quantity: 1 Set
Packaging Details: plywood pallet
Delivery Time: 95 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 12 Sets / Year
Name: UV Protection Polycarbonate Hollow Profile Extrusion Line PLC Control Material: PC
Extruder: SJ120/35 Single Screw Extruder Product Width: 1220mm 2300MM
Product Thickness: 4-6MM 8-10mm Max. Capacity: 450kg/h
Voltage: 380V , 410V , Customized Screw Design: Special Single-screw For PC
High Light:

pp film extrusion machine


pp sheet extrusion machine


pp hollow sheet extrusion line

Polycarbonate Hollow Profile Sheet Extrusion Line UV Protection PLC Control



This flexible connection PE PC PP Hollow sheet extrusion line consists of single screw extruder, melt-pump, hydraulic filter exchanging unit, hollow sheet die head, vacuum calibrating table, first haul off machine, oven, corona treating unit, cooling table, second haul off machine, trimming and length-settled cutting units and stacker etc.


PC hollow sheet is widely used in construction sunroof in buildings/halls/shopping center/stadium/public places of entertainment and public facility; Ring shield of bus station/garages/pergolas/corridors;Noise barriers for highways and urban elevated road.


Machine List :


description data
feeding system 1set
120/35 single screw extruder(High effective,Using German technology) 1set
45/30 uv co-extruder 1set
hydrulic screen changer 1set
melt pump(Swiss MAAG brand) 1set
feedblock 1set
t-die head (Mould JC-Times , Best Chinese Brand) 1set
vacuum calibrating table 1set
first stage haul off machine 1set
5000mm oven 1set
second stage haul off machine 1set
protective film laminating unit 1set
transeverse cutting machine 1set
electrical control system(SCHNEIDER Contactor,ABB Inverter) 1set


Main Technical Data:


PP/PE Hollow Sheet Extrusion Line Technical Data PC Hollow Sheet Extrusion Line Technical Data
Extruder model SJ-120,SJ-100 Extruder model SJ-120, SJ-45
Sheet width 2100mm,1220mm Sheet width 2100mm
Sheet thickness 2-8mm,2-8mm Sheet thickness 4-40mm
Max capacity 350kg/h,200kg/h Max capacity 450kg/h
Main motor power 132kw Main motor power 132kw





Polycarbonate Hollow Profile Sheet Extrusion Line UV Protection PLC Control 0
