Food Packaging PET Sheet Extrusion Line Polymer Sheet Extrusion Machine 0.15 - 1.2mm Thickness

Basic Information
Place of Origin: Qingdao, China
Brand Name: Leader
Certification: CE ISO SGS GOST
Model Number: SJ120/35
Minimum Order Quantity: 1 set
Packaging Details: plywood pallet
Delivery Time: 90-105 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 18 Sets / Year
Name: Food Packaging PET Sheet Extrusion Line Polymer Sheet Extrusion Machine 0.15 - 1.2mm Thickness Material: PET
Extruder Type: Single Screw Extruder Thickness: 0.15-1.2mm
Width: 600-1200mm Max Capacity: 600kg/h
Sheet Applicaions: Interior And Exerior Decoration , LGP HS Code: 8477209000
High Light:

pet extruder machine

,

pet sheet making machine

,

pet extrusion machine

Food Packaging PET Sheet Extrusion Line Polymer Sheet Extrusion Machine 0.15 - 1.2mm Thickness​



Summary Introduction



This PET extrusion line is specially designed for PET sheet line , which is as clear as high impact resistance

So we adopts parallet twin screw extruder  line for PET sheet and equipped with degassing system, so no

need drying or crystalizing unit



Multi components dosing feeder can control the percentage of virgin material, recycling material

and master bacth precisely.



Sheet specifications:

Usual sheet width : 300-1500mm

Usual sheet thickness :0.2-2mm



Application:



This sheet is widely used for thermoforming packing industry.



Technical parameters :



Extruder Model LMSB-90/35 LMSB-100/35 LMSB-120/35 LMS-100/65 LMSB-120/65
Sheet Width 300-610mm 500-950mm 1000-1500mm 500-950mm 1000-1500mm
Sheet Thickness 0.15-1.4mm 0.15-1.4mm 0.15-2mm 0.25-1.4mm 0.25-1.4mm
Driving Motor 75KW 90KW 132KW 90KW,75KW 132KW, 65KW
Line Speed 25m/min 25m/min 28m/min 28m/min 28m/min
Capacity 180kg/h 300kg/h 550kg/h 450kg/h 650kg/h
