PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder

Basic Information
Place of Origin: Qingdao of China
Brand Name: Qingdao Leader machinery
Certification: CE;ISO9001-2000;Bureau Veritas
Model Number: LMSB120/35
Minimum Order Quantity: 1
Price: US$120000-150000/SET
Packaging Details: Wooden Cases and Wooden Pallet
Payment Terms: L/C, T/T, Western Union
Model NO.: SJ-120/35 Condition: New
Main Electrical Parts: ABB, Omron, Rkc, Schneider, Siemens Etc Sheet Thickness: 0.2-3mm
Transport Package: Wooden Cases And Wooden Pallet Origin: Qingdao, Shandong, China
Customized: Customized Sheet Width: 800-2000mm
Trademark: Qingdao Leader Machinery Specification: CE ISO SGS GOST;BV
Max Capacity: 300kg/H-500kg/H Sheet Structure: Single Layer, 2 Layers A/B, 3 Layers A/B/A
Calibrating Method: Three Roller Calendars
High Light:

Thermoforming Packing Sheet Machinery

,

CE Certification PET Sheet Extruder

,

Thermoforming PET Sheet Extruder

PET thermoforming packing sheet machinery CE certification PET sheet extruder



PET/PETG/PMMA/PC sheet extrusion machine is one of the most advanced, mature and stable sheet extrusion lines. Compared with similar machinery, Superior performance is over 30% in integrated high efficiency. This line is also used for production of PS, PP, PE and other sheet products.



Uses: widely used instruments, instrument parts, lighting, decoration, construction, aircraft, auto parts, medical equipment, technology products, electrical insulation materials, specimens, signs, and a variety of light industry, culture and education, and daily necessities.



PET/PBT Single Layer or Multi-layer Sheet Extrusion Line

This line is specially used for producing PP/PE/PS/ABS/PVC single layer or multi-layer sheet or plate, suitable in the fields of packaging, stationery, chemicals, construction, household appliances and so on.


Main technical data:
1. Usual sheet width: 700, 900, 1020, 1200, 1300, 1400, 1500, 1700, 1800, 2100, 2200mm
2. Usual sheet thickness: 0.5-2mm, 1.5-10mm, 6-20mm, 3-30mm

Extruder: Special screw structure, imported world-known thermocontrollers, electronics, hard gear face reducers to ensure high effective material extrusion capacity.

T -type die head: suitable compression ratio to ensure uniform flow stability.

Three-roller calendar: According to the material properties, adopting vertical three-roller, oblique three-roller, horizontal three-roller calendar. Internal roller temperature control using a unique flow channel, so that the stability of uniform distribution roller. The independent oil temperature control for three roller to ensure more stable and exact control.

Cooling frame: According to product specifications, configurations with different specifications of the stainless steel

cooling rollerEdge-cutting devices: Trimming can be divided into manual and automatic, three-dimensional configuration tool adjustment device, width adjustable.

Cut off machine: Saw cutting or knife cutting, thin type and non-friable type sheet generally usually knife cut, adopted high-quality alloy cutting tools, sharp and durable.

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 0

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 1

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 2

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 3

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 4





COMPANY CERTIFICATIONS OF:

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 5

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 6

COMPANY CERTIFICATIONS OF:

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 7

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 8

The 34th International Extrusion on Plastics and Rubber Industries

PET Thermoforming Packing Sheet Machinery CE Certification PET Sheet Extruder 9

OTHER PLASTIC SHEET EXTRUSION LINE RECOMMEDATION
1. PC/PP hollow profile sheet/hollow grid sheet extrusion line
Processing material: PC/PP virgin material plus recycle material
Thickness range: 2mm-4mm-6mm-8mm-10mm-12mm
Net sheet width: 1220mm-2100mm
Layer structure: Single layer or multi-layer
Capacity: 200-600kg/h
Application: Ads. Decoration, roofing, packaging, printing, etc.

2. ABS/HIPS sheet extrusion machine:
Processing material: ABS/HIPS virgin pellets plus recycle material
Thickness range: 1-6mm
Net Sheet width: 1200mm-1600mm-2100mm(or as per customer's requirement)
Layer Structure: Single layer or multi-layer
Capacity: 400-800kg/h
Application: Vacuum forming, thermoforming, refrigerator inner layer, suitcase, etc.

3. ABS/PMMA sheet extrusion machine:
Processing material: ABS/PMMA virgin pellets plus recycle material
Thickness range: 1-8mm
Net sheet width: 1200mm-1600mm-2100mm(or as per customer's requirement)
Layer structure: Single layer or multi-layer
Capacity: 400-800kg/h
Application: Vacuum forming, bathtub, etc.

4. PP PE foam board/sheet extrusion line
Processing material: PP, PE , Foam additives, master batch
Thickness range:0.8-3-12mm
Net sheet width: 600mm-1260mm-
Layer structure: Single layer or double layers (A/B), three layers (A/B/A, A/B/C)
Capacity: 150-500kg/h
Application: stationery, containers, handbags, heat insulation material, construction, food packing, automobile area, industry application, sports fields etc.

5. PE HDPE sheet extrusion machine:
Processing material: HDPE/LDPE/LLDPE virgin pellets plus recycle material
Thickness range: 1-2.5mm, 3-35mm
Net sheet width: 1200mm-1600mm-1800mm-2500mm-3000mm-40000mm-6000mm-8000mm
Layer structure: Single layer or multi-layer
Capacity: 200kg/h-1200kg/h
Application: Packaging, construction, water-proof, water-drainage, Geomembrane film, etc.

6. PC/GPPS/PMMA sheet extrusion machine:
Processing material: PC/GPPS/PMMA virgin pellets plus recycle material
Thickness range: 1-12mm
Net sheet witdh: 600mm-1220mm-2100mm(or as per customer's requirement)
Layer Structure: Single layer or multi-layer
Capacity: 400-600kg/h
Application: Ads., decoration, roofing, etc.

7. PP/PS sheet extrusion machine:
Processing material: PP/PS virgin pellets plus recycle material;
Thickness range: 0.15-2mm
Net sheet width: 650mm-720mm-1000mm-1300mm-1500mm(or as per customer's requirement)
Layer structure: Single layer or multi-layer
Capacity: 200kg/h-1000kg/h
Application: Thermoforming(cup, bowl, etc. ), stationery, printing sheet, packaging, etc.

8. PET sheet extrusion machine:
Processing material: PET virgin pellets(APET or PETG) plus flakes; Or 100% flakes
Thicknes range: 0.2-1.5mm
Net sheet width: 650mm-1500mm(or as per cusotmer's requirement)
Layer structure: Signle layer or multi-layer
Capacity: 150-500kg/h
Application: Thermoforming(cup, bowel, etc. ), stationery, printing sheet, packaging, etc.
9. PVC sheet/edge banding sheet/marble sheet machine:
Processing material: PVC power plus other additive
Thickness range: 0.15-1mm; 1-3mm; 3-12mm
Net sheet width: 650mm-2000mm-3000mm( or as per customer's requirements)
Layer structure: Single layer or multi-layer
Capacity: 200kg/h-500kg/h
Application: Thermoforming, stationery, printing, payment card, SIM card, construction, etc.
10. EVA car interior decoration sheet extrusion line
Processing material: EVA and other additives
Thickness range: 1-8mm
Width range: 1000-1800mm
Layer strcuture: single layer
Capacity: 500-800kg/h
Application: automotive sealing strips, sound insulation cushion, sound absorption sheets,
automobile tail box, fenders, car interior and exterior decoration parts etc.
11. PVC+PMMA Glazed roofing tiles/corrugated sheet extrusion machine
Processing material: PVC, PMMA and other additives
Thickness range: 1-8mm
Width range: 720mm, 880mm, 1040mm
Layer structure: A/B, A/B/A, A/B/C
Capacity: 400kg/h
Application: garden-style factory, tourist scenic spots, pavillions, hotels, family building etc.
