| Place of Origin: | Qingdao China |
|---|---|
| Brand Name: | Leader |
| Certification: | CE ISO SGS GOST |
| Model Number: | SJ-180/30 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotabile |
| Packaging Details: | plywood pallet |
| Delivery Time: | 90 Workdays |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 15 Sets / Year |
| Name: | EVA Sheet Extrusion Line 1-8mm Thickness 2000mm Width | Material: | EVA |
|---|---|---|---|
| Extruder Type: | Single Screw Extruder | Product Width: | 2000mm |
| Product Thickness: | 1-8mm | Max. Capacity: | 700kg/h |
| High Light: | eva foam maker,eva moulding machine |
||
EVA Sheet Extrusion Line 1-8mm Thickness 2000mm Width
EVA Car Interiors Decoration Sheet Extrusion Line Width of 1800mm
Production Line Description:
180mm (150mm) Gradient single screw extruder
This extruder adopts special gradient type design screws. The screw extruder diameter
changes from 180mm to 150mm. This gradient screw is specially designed for the EVA
sheets. The cooling method adopts cooper pipes water cooling. The vacuum exhausting
device is also installed.
MAIN MACHINE CONFIGURATIONS:
| Item | Description | Data |
| 1 | Material mixer | 1 set |
| 2 | Pressure kneader | 1 set |
| 3 | Automatic transmission hoist | 1 set |
| 4 | Forced double screw feeding machine | 1 set |
| 5 | 180mm (150mm) Gradient single screw extruder | 1 set |
| 6 | 2150mm T type die head | 1 set |
| 7 | Hydraulic exchanging unit | 1 set |
| 8 | Three rollers calendars with rollers thermoforming machine | 1 set |
| 9 | Double position double sides film laminating units | 1 set |
| 10 | Cooling frame | 1 set |
| 11 | Haul off machine and edge cutting units | 1 set |
| 12 | Sheets surface corona device | 1 set |
| 13 | Cutting machine (guillotine) | 1 set |
| 14 | Stacker | 1 set |
| 15 | Industrial water chiller | 1 set |
