Zhejiang Mingdi Extrusion Machinery Co.,Ltd
| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | MINGDI |
| Certification: | CE, ISO |
| Model Number: | MGL130/38 |
| Minimum Order Quantity: | One set |
| Price: | $160000-$170000 |
| Packaging Details: | wooden box |
| Delivery Time: | 90days |
| Payment Terms: | T/T |
| Supply Ability: | 180-200 sets/year |
| Screw: | Twin Screw | Capcity: | 400-1200kg/h |
|---|---|---|---|
| Screw Material: | Stainless Steel | Main Motor Power: | 22kW |
| Cooling Method: | Water Cooling Fan Cooling | Screw Type: | Parallel Twin Screw |
| Barrel Heating Zones: | 5 | Screw Rotation Speed: | 0-500rpm |
| Control System: | PLC | Main Extruder: | Twin Screw Extruder |
| Assembly Structure: | Integral Type Extruder | Motor: | Siemens |
| Barrel Cooling Power: | 1.5kW | Feeding Mode: | Multiple Feed |
| Highlight: | dual screw plastic sheet extrusion line,automatic pla sheet extrusion line,automatic plastic sheet extrusion line |
||
| Attribute | Value |
|---|---|
| Screw | Twin Screw |
| Capcity | 400-1200kg/h |
| Screw Material | Stainless Steel |
| Main Motor Power | 22kW |
| Cooling Method | Water Cooling fan cooling |
| Screw Type | Parallel Twin Screw |
| Barrel Heating Zones | 5 |
| Screw Rotation Speed | 0-500rpm |
| Control System | PLC |
| Main Extruder | Twin Screw Extruder |
| Assembly Structure | Integral Type Extruder |
| Motor | Siemens |
| Barrel Cooling Power | 1.5kW |
| Feeding Mode | Multiple Feed |
PET is a highly crystalline polymer with a milky white or light yellow color surface that is smooth and shiny. Good creep resistance, fatigue resistance, abrasion resistance and dimensional stability, small wear and high hardness, with the greatest toughness among thermoplastics: good electrical insulation properties, little influence by temperature, but poor corona resistance. Non-toxic, weather resistance, good chemical resistance, low water absorption, weak acid and organic solvent resistance, but not resistant to hot water immersion, not resistant to alkali.
MINGDI MACHINERY also provides these additional material options:
PLA has good thermal stability, processing temperature 170~230 °C, good solvent resistance, can be processed in a variety of ways, such as extrusion, spinning, biaxial stretching, injection blow molding. In addition to being biodegradable, products made of polylactic acid have good biocompatibility, gloss, transparency, feel and heat resistance.
