Nonwoven Laminated PE Geomembrane Waterproof Sheet Extrusion Line 0.939g/Cm3 Sheet Density

Basic Information
Place of Origin: Qingdao, China
Brand Name: Leader Machinery
Certification: CE ISO SGS GOST
Model Number: SJ120 , SJ150
Minimum Order Quantity: 1 set
Packaging Details: plywood pallet
Delivery Time: 90-105 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 20 Sets / Year
Name: Nonwoven Laminated PE Geomembrane Waterproof Sheet Extrusion Line 0.939g/Cm3 Sheet Density Material: PE PVC TPO
Width: 2000mm-3000mm-6000mm-8000mm Thickness: 0.5-3mm
Sheet Density: 0.939g/cm3 Max. Capacity: 500-1000kg/h
High Light:

pvc sheet extruder

,

pe extrusion line

,

pe extrusion machine

Nonwoven Laminated PE Geomembrane Waterproof Sheet Extrusion Line 0.939g/Cm3 Sheet Density

Introduction :


PE waterproof sheet is also known as polyethylene polypropylene composite sheets. It is a new type of composite waterproof sheet which is extruded and laminated in one process by sheet extrusion line added with anti-aging agent, stabilizer, binder, and together with high strength non-woven fabric etc.

HDPE geomembrane , also is called extra-width waterproof sheets , widely used for

waterproofing usage in industrial & civil buildings , including the green roof , flat and the sloping roof .

underground waterproof reservior ,dam , pool .swimming pool

waterproof usage in tunnel drainage , grai depot , artificial engineering , landfill , artificial lake  foundation moisture-proof .


Sheet Specification :



Material PE PE
Sheet thickness 0.5-3mm 0.5-3mm
Sheet width 1000-4000mm 5000-8000mm
No. Item Value
    0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm 3.00mm
1 Density
(g/cm3)
0.939
2 Tensile properties
  Yield strength
(N/mm)
11 15 18 22 29 37 44
  Break strength
(N/mm)
20 27 33 40 53 67 80
  Yield elongation/% 12
  Break elongation/% ≥450
3 Tear resistance/N 93 125 156 187 249 311 374
4 Puncture resistance/N 240 320 400 480 640 800 960
5 Stress crack resistance/h ≥1500




Nonwoven Laminated PE Geomembrane Waterproof Sheet Extrusion Line 0.939g/Cm3 Sheet Density 0
