CE Standard PP/PS/HIPS/PE Sheet Extrusion Line with Continuous Screen Exchanger

Basic Information
Place of Origin: Qingdao China
Brand Name: Leader Machinery
Certification: CE ISO SGS GOST
Model Number: SJ120/35
Minimum Order Quantity: 1 Set
Packaging Details: plywood pallet and transparent film package
Delivery Time: 95 Workdays
Payment Terms: T/T, , Western Union, D/P
Supply Ability: 22 Sets / Year
Name: CE Standard PP/PS/HIPS/PE Sheet Extrusion Line With Continuous Screen Exchanger Extruder: Single Screw EXtruder SJ120/35
Product Width: 700-3000mm Product Thickness: 0.2-2mm
Max. Capacity: 200kg/h 300kg/h 500kg/h Main Electrical Parts: ABB , OMRON , RKC , Schneider , SIEMENS
Sheet Application: Thermoforming Packing
High Light:

pp extrusion machine


pp sheet making machine

CE Standard PP/PS/HIPS/PE Sheet Extrusion Line with Continuous Screen Exchanger


Production Flows:


Vacuum Thermoforming Polystyrene PS PP sheet making machine, Polystyrene PS PP sheet

extrusion machine,Polystyrene PS sheet production line

This Plastic PP/PS/PET Sheet Production Line Maachineis specially designed for mono/multi Layer sheet for packing indrustry. The technology of "Single Screw extruding with low dew-point dehumidifying system " for high quality products in high transparency without buddle, which will be very important for thermoforming.

produce PP PS single layer or multi-layers sheet or plate. The PP PS sheet has wide application

in the Vacuum themoforming field. The PP PS sheet can be manufactured to plastic cups, tray, boxes


Product Info :

1. Screw apply special design of mixing and plasticizing function.
2. Coat hanger type die apply special double throttle design, much more accurate adjustment of width of production.
3. ± 1Degrees Celsius temperature control to make more accurate plasticizing process and sheet width control.
4. Three-roller calender apply level, vertical and 45degrees bevel type and can be lifted freely.
5. The sheet width is accurately controlled by adjusting the screw and rollers
6. Separate control system of roller temperature can make thickness equably extrusion
7. Slicing machine, accurate board length and quantity.
8. Winder with big torque motor, regulate its speed and tension force freely.
9. Equipped with metering machine to set the length of product.


Components Consist:


Vacuum feeding machine 1 set
Hopper dryer 1set
Single Screw Extruder 1set
Hydraulic filter exchanging unit and melt pump 1 set
T-type Die Head 1 set
Three-roller Calendar 1 set
Cooling Frame & Edge Cutting Knives 1 set
haul off machine and cutting machine 1 set
Double position winder 1 set


Sheet Specifications :


1 Sheet width 700-3000mm
2 Sheet thickness 0.2-2mm
3 Type PP/PS/HIPS/PE single layer/mono layer sheets
4 Raw material 1. Can be virgin plastic pet material
2. Can be recyclable material, like PET Bottle Flakes




CE Standard PP/PS/HIPS/PE Sheet Extrusion Line with Continuous Screen Exchanger 0
