High Impact Bullet Proof Polycarbonate Plate Extrusion Machine Single Screw Extruder

Basic Information
Place of Origin: Qingdao , China
Brand Name: Leader
Certification: CE . ISO . SGS . GOST
Model Number: SJ120-33 Extrusion Line
Minimum Order Quantity: 1 set
Price: US $320,000~350,000/SET
Packaging Details: plywood pallet
Delivery Time: 90-105 workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 22 Sets / Year
Width: 1200mm 2100mm Or Customerized Name: High Impact Bullet Proof Polycarbonate Plate Extrusion Machine Single Screw Extruder
Material: PC PMMA Usage: Automative Industry , Film Switch Of Electronics
Extruder Type: Single Screw Extruder Screw Diameter: 120mm
High Light:

polycarbonate sheet manufacturing machine

,

plastic sheet making machine

High Impact Bullet Proof Polycarbonate Plate Extrusion Machine Single Screw Extruder



Introduction :



This machine is specially used to produce the polycarbonate universal solid sheets , which is as clear as glass but the density of PC is only half of glass . And the PC solid sheet is with high impact resistance , which is also called "unbreakable glass" . By changing the three rollers calendars , this line can also produce frosted solid sheets , diffusion solid sheets , embossed solid sheets and anti-scratch solid sheet etc for different applications .



Sheet Specification :



1. Thickness : 1.8-16mm

2. Width range :<=2100mm
​3. Length: Any dimension
​4. Color : Clear , Blue , Green , Opal , Brown , Blue , Green , etc .

Solid Sheet Applications :


PC solid sheet is easy to be shaped with cold bending , equipment and heat synthesis processing accordingly , which used widely in all kinds of architecture , engineering and decoration etc .

1. lighting roofing
​2. advertisement light box
3. carport and awnings
4. sound barrier

​5. protective & police device
6. indoor partition
​7. Indoor ceiling etc .


Technical Parameter:



Main extruder Dia. 120mm 130mm
Main screw L/D ratio 35:1 38:1
Main extruder drive 185kw 250kw
Co-extruder Dia. 45mm 45mm
Co-extruder L/D ratio 30:1 30:1
Co-extruder drive 22kw 22kw
Thickness of sheet 0.8-8mm 1.5-10mm
Width of sheet 1000-1560mm 1220-2100mm
Output ≥420kg/h ≥600kg/h
Power installed 180kw 250kw





High Impact Bullet Proof Polycarbonate Plate Extrusion Machine Single Screw Extruder 0
