PC PMMA Solid Sheet Extrusion Line High Capacity High Speed

Basic Information
Place of Origin: Qingdao, China
Brand Name: Leder
Certification: CE ISO SGS GOST
Model Number: SJ-120/35
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: plywood pallet
Delivery Time: 60 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 15 Sets / Year
Name: PC PMMA Solid Sheet Extrusion Line High Capacity High Speed Material: PC
Extruder: Single Screw Extruder Product Width: 1220mm
Product Thickness: 1.5-10mm Max. Capacity: 350kg/h
High Light:

polycarbonate sheet extruders

,

polycarbonate sheet making machine

PC PMMA Solid Sheet Extrusion Line High Capacity High Speed​



Introduction:



 This pc/pmma/gpps/ps solid sheet/plate extrusion line is designed to produce

PC/PMMA/PS Optical tranparent sheet, widely used in screens, advertisement

material, artical lens. PC everlasting plate, PMMA and PS color and embossed

plates are mainly used in ad-material, architecture material and so on.



Main technical Data:



main extruder model 120/35 130/38
main driving motor power 185kw 250kw
Co-extruder model 45/30 45/30
Co-extruder driving motor 22kw 22kw
Sheet width 800-1560mm 1220-2100mm
Sheet thickness 0.8-8mm 1.5-10mm
Max output >=300kg/h >=450kg/h



PC PMMA Solid Sheet Extrusion Line High Capacity High Speed 0PC PMMA Solid Sheet Extrusion Line High Capacity High Speed 1
